NDE-8504-RT Fixed dome 8MP HDR 12-40mm PTRZ IP66
Product No. F.01U.384.554
NDE-8504-R Fixed dome 8MP HDR 3.9-10mm PTRZ IP66
Product No. F.01U.396.604
NDE-8514-R Fixed dome 8MP HDR 3.9-10mm PTRZ IP66
NDE-8514-RT Fixed dome 8MP HDR 12-40mm PTRZ IP66
NDE-8504-R-W Dome 8MP HDR 3.9-10mm PTRZ IP66 WM （EOL)
Wireless or remote configuration and commissioning with the Project Assistant app. Pan, Tilt, Roll and Zoom (PTRZ) to set the camera to the required field of view, without having to touch the camera or lens
1/1.8" 4K UHD sensor and starlight technology to provide highly detailed images even in extreme low-light situations
High Dynamic Range to see every detail in both bright and dark areas of the scene
Built-in Intelligent Video Analytics with object detection to trigger alerts and quickly retrieve data with the highest levels of reliability
Camera Trainer to train the camera to recognize user-specified target objects for both moving and non-moving objects
Key Specifications
Field of View wide (°) 12.60 – 36 °
Frame rate (fps) 1 – 30 fps
Impact protection (EN 50102) IK10
IP rating IP66
Lens focal length (mm) 12 – 40 mm
Minimum illumination in color (lx) 0.0860 lx
Minimum illumination in monochrome (lx) 0.0165 lx
Operating temperature (°C) -50 – 60 °C
Operating temperature (°F) -58 – 140 °F
Resolution 1920 x 1080
Sensor type 1/1.8 inch CMOS
Video compression H.264 (ISO/IEC 14496-10)
Parts included with this product
Quantity Component
1 FLEXIDOME IP 8000i camera
1 T-20 security Torx bit
1 Quick installation guide
1 Safety information
2 Rubber grommet for the Ethernet cable
1 Network patch cable 50 cm
1 10-pin I/O connector
1 2-pin power connector
1 Cable conduit for side entry
1 Washer for cable conduit
1 Adapter plate for cable conduit (? 3/4" / M25)
1 Adapter plate for cable conduit (? 1/2" / M20)
3 Identification label
